TRUMATIC L3050

Laser cutting machine (CO2)

Category	2D Laser Cutting Machines
Condition	Used
Year	2002
Availability	Available
ID	10111

Isaac Mateo

+34 932 711 191

+34 652 098 501

Maximum material thickness stainless steel

0mm

Maximum material thickness aluminium

0mm

Maximum material thickness mild steel

0mm

Beam ON Working hours	40.100 h
Consumption values CO2	1 l/h
Consumption values He	13 l/h
Consumption values N2	6 l/h
Control	SIEMENS SINUMERIK 840D
Dimensions (long x wide x high)	11.250 x 4.600 x 2.400 mm
Laser Output	5 kW
Laser Type	CO2
Max. workpiece weight	900 kg
Maximum material thickness aluminium	12 mm
Maximum material thickness mild steel	25 mm
Maximum material thickness stainless steel	25 mm
Positioning speed X/Y	200 m/min
Simultaneous positioning speed	300 X+Y m/min
Weight	12.000 kg
Working area (X x Y x Z)	3.000 x 1.500 x 100 mm
