FERROMATIK

K-TEC 450 S

450t injection molding machine

Category	250 to 499t Injection moulding machines
Condition	Used
Year	2016
Availability	Available
ID	11215

Isaac Mateo

+34 932 711 191

|

+34 652 098 501

Clamping force

0kN

with SERVO

Air Valves	4
Clamping force	4.500 kN
Distance between tie-bars (h x v)	825 × 825 mm
Dry cycle time	3 - 578 sec/mm
Ejector stroke / force max.	85 / 200 mm / kN
Injection pressure	1.921 bar
Injection rate	2.850 cm³/s
Injection volume	2.290 cm³
Mold opening force	185 kN
Mould height max	1.420 mm
Mould height min	420 mm
Mould opening stroke max	1.000 mm
Operating hours	100.700
Platen size (h x v)	1.195 x 1.267 mm
Power: installed max	90 + 50,6 kW
Screw diameter	90 mm
Screw L/D ratio	20
Shot weight max	2.084 g
Weight	30.000 kg

No videos available

FERROMATIK K-TEC 450 S Technical Specification Sheet	View PDF
