ENGEL

VICTORY VC 750 / 220 TECH PRO

220t injection molding machine

Category	100 to 249t Injection moulding machines
Condition	Used
Year	2010
Availability	Sold
ID	10128

Clamping force

0kN

Clamping force	2.200 kN
Daylight between platens max	1.050 mm
Ejector force	80 kN
Injection pressure	2.360 bar
Injection rate	230 cm³/s
Injection volume	318 cm³
Mould height min	300 mm
Mould opening stroke max	750 mm
Nozzle stroke / force max.	67 mm / kN
Nozzle stroke max	350 mm
Oil tank capacity	610 l
Operating hours	55.008
Platen size h	860 mm
Platen size v	580 mm
Screw diameter	45 mm
Screw L/D ratio	20
Screw speed	230 rpm
Shot weight max	293 g

No videos available

ENGEL VICTORY VC 750 / 220 TECH PRO Technical Specification Sheet	View PDF
