ENGEL

VICTORY VC 750 / 220 TECH PRO

220t injection molding machine

Category	100 to 249t Injection moulding machines
Condition	Used
Year	2009
Availability	Available
ID	10809

Vanessa Fuguett

+34 932 711 191

|

+34 932 711 191

Clamping force	2.200 kN
Daylight between platens max	1.050 mm
Dimensions (long x wide x high)	6.200 x 1.800 x 2.200 mm
Injection pressure	1.910 bar
Injection rate	283 cm³/s
Injection volume	392 cm³
Mould height min	300 mm
Nozzle stroke / force max.	350/67 mm / kN
Oil tank capacity	610 l
Screw diameter	50 mm
Screw L/D ratio	20
Screw speed	230 rpm
Shot weight max	361 g
Weight	11.600 kg

No videos available

ENGEL VICTORY VC 750 / 220 TECH PRO Technical Specification Sheet	View PDF
