ENGEL

VICTORY VC 330 / 150 TECH PRO

150t injection molding machine

Category	100 to 249t Injection moulding machines
Condition	Used
Year	2005
Availability	Sold
ID	10124

Clamping force	1.500 kN
Daylight between platens max	900 mm
Ejector force	61 kN
Injection pressure	2.400 bar
Injection rate	77 cm³/s
Injection volume	78 cm³
Mould height min	300 mm
Mould opening stroke max	600 mm
Nozzle stroke / force max.	47 mm / kN
Nozzle stroke max	250 mm
Oil tank capacity	450 l
Operating hours	44.574
Platen size h	750 mm
Platen size v	520 mm
Screw diameter	25 mm
Screw L/D ratio	24,8
Screw speed	400 rpm
Shot weight max	72 g
