ENGEL

VICTORY VC 330 / 120 TECH PRO

120t injection molding machine

Category	100 to 249t Injection moulding machines
Condition	Used
Year	2006
Availability	Available
ID	11143

Isaac Mateo

+34 932 711 191

|

+34 652 098 501

Clamping force

0kN

Clamping force	1.200 kN
Daylight between platens max	800 mm
Dimensions (long x wide x high)	4.400 x 1.500 x 2.000 mm
Ejector force	47 kN
Heating zones	2
Injection pressure	2.200 bar
Injection volume	78 cm³
Injection volume	113 cm³
Mould height max	n/a mm
Mould height min	300 mm
Mould opening stroke max	500 mm
Nozzle stroke max	250 mm
Oil tank capacity	300 l
Platen size (h x v)	740 x 470 mm
Power: installed max	25 kW
Screw diameter	25 mm
Screw speed	400 rpm
Shot weight max	72 g
Weight	7.300 kg
