VICTORY VC 200 / 80 TECH PRO

80t injection molding machine

Category	10 to 99t Injection moulding machines
Condition	Used
Year	2017
Availability	Sold
ID	10409

Clamping force

0kN

Includes robot ENGEL, Core Pullers, Servo ecoDrive, Mold Temperature Controller

Clamping force	800 kN
Air Valves	yes
Control	CC300
Core pullers	yes
Daylight between platens max	700 mm
Dimensions (long x wide x high)	3.900 x 1.500 x 2.000 mm
Distance between tie-bars (h x v)	n/a mm
Ejector stroke / force max.	100 / 39,8 mm / kN
Heating zones	4
Injection pressure	2.090 / 2.400 (max) bar
Injection rate	104 cm³/s
Mould height min	250 mm
Mould opening stroke max	457 mm
Nozzle stroke / force max.	230 / 28,3 mm / kN
Oil tank capacity	170 l
Operating hours	100
Platen size (h x v)	670 x 600 mm
Power: installed max	77 kW
Screw diameter	25 mm
Screw L/D ratio	24,8
Screw speed	300 rpm
Weight	5.200 kg
