ENGEL

E-MOTION 740-150

150t all-electric injection molding machine

Category	100 to 249t Injection moulding machines
Condition	Used
Year	2008
Availability	Sold
ID	10323

Clamping force	1.500 kN
Dimensions (long x wide x high)	6.000 x 2.000 x 2.100 mm
Injection pressure	2.000 bar
Injection volume	392 cm³
Nozzle stroke max	400 mm
Operating hours	58.221
Platen size h	970 mm
Platen size v	755 mm
Screw diameter	50 mm
Shot weight max	360 g
Weight	16.000 kg
