ENGEL

Name: VANTO MACHINES - Purchase and Sale of used machines, second hand machinery
Address: Ronda Sant Pere, 16, Barcelona, Spain, Catalunya, 08010
Telephone: (+34) 932 711 191

DUO 1800-700 WPX

700t injection molding machine

Category	500 to 749t Injection moulding machines
Condition	Used
Year	2010
Availability	Available
ID	11093

Isaac Mateo

+34 932 711 191

+34 652 098 501

Clamping force	7.000 kN
Core pulls	2 x 2
Daylight between platens max	1.850 mm
Dimensions (long x wide x high)	8.300 x 2.300 x 2.300 mm
Distance between tie-bars h	1.100 mm
Distance between tie-bars v	960 mm
Ejector force	95 kN
Heating zones	5
Injection pressure	3.200 bar
Injection rate	268 cm³/s
Injection volume	737 cm³
Mould height max	950 mm
Mould height min	450 mm
Mould opening stroke max	1.400 mm
Nozzle stroke / force max.	0 mm / kN
Nozzle stroke max	0 mm
Oil tank capacity	690 l
Platen size h	1.510 mm
Platen size v	1.440 mm
Power: installed max	55 kW
Screw diameter	60 mm
Screw L/D ratio	20
Screw speed	0 rpm
Weight	37.000 kg

No videos available

There are no available documents

ENGEL

DUO 1800-700 WPX

700t injection molding machine
