ARBURG

720 S ALLROUNDER 3200 - 2100

320t injection molding machine

Category	250 to 499t Injection moulding machines
Condition	Used
Year	2014
Availability	Sold
ID	11121

Clamping force

0kN

Clamping force	3.200 kN
Daylight between platens max	1.000 - 1.400 mm
Dimensions (long x wide x high)	7.750 x 2.250 x 2.666 mm
Distance between tie-bars (h x v)	720 x 720 mm
Injection pressure	2.000 bar
Injection volume	1.078 cm³
Operating hours	38.432
Platen size (h x v)	1.040 x 1.040 mm
Screw diameter	70 mm
Weight	17.700 kg

ARBURG 720 S ALLROUNDER 3200 - 2100 Technical Specification Sheet	View PDF
